current trackmaps

  • Current tramway trackmap

    Complete trackmap of the SWA.

  • share

  • Copyright

    These drawings are protected by copyright. A further use is possible by application of the Creative-Commons-Lizenz by-nc-sa.

  • weitere Pläne

  • Königsplatz

    Situation before an after the reconstruction in 2012.
    trackmap


    • 31.03.2018
      Several stops renamed.
    • 16.06.2017
      Planned line to Königsbrunn added.
    • 05.02.2016
      Zahlreiche Haltestellen umbenannt. Danke für den Hinweis.
    • 26.08.2015
      Unterführung Hauptbahnhof korrigiert. Danke für den Hinweis.
    • 18.11.2014
      Mehrere Haltestellen umbenannt, danke für die Hinweise.
    • 15.12.2013
      Haltestelle Königsplatz wieder in Betrieb.

    profile

    network data tramway
    inauguration:
    08.05.1881
    track gauge:
    1000 mm
    overhead wiring:
    600 VDC
    operator:
    Augsburger Verkehrsgesellschaft (AVG)
    network, total length:
    40,6 km
    rolling stock (2012)
    trams:
    70
    trams withdrawn from use:
    20
    trailers withdrawn from use:
    16
    historic trams:
    1
    units needed for regular service
    regular service:
    75
    during reconstruction of Königsplatz:
    40
    partly estimated

    external maps

    Transit map

    on the SWA website.
    Plan

    network map

    at Wikipedia
    Plan
