current trackmaps

  • Current tramway trackmap

    Complete network of the BVG in Berlin, the Schöneicher-Rüdersdorfer and the WoltersdorferStraßenbahn.

    trackmap in the viewer trackmap at pdf trackmap at svg key

  • Current subway trackmap

    Complete network of the BVG in Berlin.

    trackmap in the viewer trackmap at pdf trackmap at svg key

  • share

  • Copyright

    These drawings are protected by copyright. A further use is possible by application of the Creative-Commons-Lizenz by-nc-sa.

    • weitere Pläne

  • Adlershof

    Situation before and after the construction of the line extention 2008.
    trackmap

    Buschallee

    Situation until April 2008 before the start of the reconstruction.
    trackmap

    Schloßplatz Köpenick

    Situation until November 2000 before the start of the reconstruction.
    trackmap

    Mehringdamm

    Situation before and after the reconstruction 1966.
    trackmap

    Unused tunnels

    The unused tunnels of the Berlin subway network. (german only)
    to the page


    • last updates

    • 14.07.2019
      Tram: Construction works at Karlshorst added.
    • 29.01.2019
      Tramway: Planning for the new stop at S Schöneweide added.
    • 13.10.2018
      Tram: Eldenaer Straße reconstructed.
    • 26.05.2018
      Tram: End of single track operation at Schöneweide station.
    • 12.05.2018
      subway: Line 3 extended to Warschauer Straße.
    • 26.03.2018
      subway: Track numbers and proposed lines added.

    profile

    network data Berlin tramway
    inauguration:
    		22.06.1865
    track gauge:
    		1435 mm
    stops:
    		377
    network, total length (2012):
    		191,3 km
    Rolling Stock Berlin tramway (2012)
    trams:
    		396
    maintenance and service vehicles:
    		2
    trams withdrawn from use:
    		79
    trailers withdrawn from use:
    		44
    historic trams:
    		~50
    thereof in use:
    		7
    historic trailers:
    		7
    units needed for regular service:
    		242
    network data Berlin subway
    inauguration:
    		18.02.1902
    track gauge:
    		1435 mm
    stops:
    		173
    network, total length (2012):
    		145,6 km
    Rolling Stock Berlin subway (2012)
    metro cars (single):
    		1242
    U2: 8-car-units; U4, U55: 2-car-units; other lines: mostly 6-car-units
    maintenance and service vehicles:
    		2
    historic metros:
    		10
    units needed for regular service:
    		155
    network data SRS
    inauguration:
    		28.08.1910
    track gauge:
    		1000 mm
    network, total length (2012):
    		14,1 km
    Rolling Stock SRS (2012)
    trams:
    		7
    units needed for regular service:
    		4
    partly estimated
