  • Current tramway trackmap

    Complete tracknetwork of the Holding Graz.

    show trackmap trackmap as pdf trackmap as svg key

  • share

  • Copyright

    These drawings are protected by copyright. A further use is possible by application of the Creative-Commons-Lizenz by-nc-sa.

  • Ausführliche Definitionen der im Gleisplan verwendeten Symbole und Darstellungen.

    • current and upcoming projects

      Short-time construction works with no effect on the trackmap are not listed here.

    • Remise III

      Erweiterung um 4 Abstellgleise, Neubau einer Waschanlage, Umbau der Werkstatthalle.
      in Bau | proposed inauguration: noch offen
      drawn on the trackmap | website

    • Innenstadtentflechtung

      Etwa 1 km Neubaustrecke via Belgiergasse und Vorbeckgasse mit Neubau der Tegetthoffbrücke.
      in Bau | proposed inauguration: Ende November 2025
      drawn on the trackmap

    • Hilmteichstraße

      Zweigleisiger Ausbau zwischen Hilmteich und Mariagrün.
      geplant Baubeginn: Anfang 2026 | proposed inauguration: Ende 2027
      drawn on the trackmap

    • Gösting

      Neubaustrecke von der Haltestelle Roseggerhaus nach Gösting
      Trassenfindung | proposed inauguration: noch offen
      outlined on the trackmap

    • Webling

      Neubaustrecke von der Haltestelle Roseggerhaus oder Jakominiplatz über Reininghaus nach Webling
      Trassenfindung | proposed inauguration: noch offen
      outlined on the trackmap

    profile

    network data
    inauguration:
    		08.07.1878
    track gauge:
    		1435 mm
    overhead wiring:
    		600 VDC
    operator:
    		Holding Graz Linien
    network, total length:
    		33,5 km
    rolling stock (2020)
    trams:
    		85
    historic trams:
    		10
    historic trailer:
    		10
    historic maintenance cars:
    		6

    last updates

    • 22.12.2024
      Proposed second track to Mariatrost added.
    • 20.07.2024
      Plans for the extension of Remise II added.
    • 01.07.2024
      Reconstruction of Remise 3.
    • 25.06.2023
      Reconstruction of loop and stop Wetzelsdorf.
    • 28.11.2021
      New lines to Reininghaus and Smart City in operation.
    • 03.10.2021
      New stop Münzgrabenkirche under construction.
