trackmaps

  • Current trackmap

    Complete trackmap if the tramway and funicular in Innsbruck.

    show trackmap trackmap as pdf trackmap as svg key

  • share

  • Copyright

    These drawings are protected by copyright. A further use is possible by application of the Creative-Commons-Lizenz by-nc-sa.

  • Ausführliche Definitionen der im Gleisplan verwendeten Symbole und Darstellungen.

    • current and upcoming projects

      Short-time construction works with no effect on the trackmap are not listed here.

    • Völs

      Verlängerung der Linie 5 nach Völs
      Planung abgeschlossen | proposed inauguration: noch offen
      drawn on the trackmap

    • Stadiontram

      Neubaustrecke von Bretterkeller bis Philippine-Welser-Straße durch das Stadtentwicklungsgebiet Sillhöfe.
      Machbarkeitsuntersuchung | proposed inauguration: noch offen
      outlined on the trackmap

    • Anbindung DEZ

      Neubaustrecke vom Südring zum Einkaufszentrum DEZ.
      Machbarkeitsuntersuchung | proposed inauguration: noch offen
      outlined on the trackmap

    • Tramachse Reichenau

      Neubaustrecke von der Gabelsbergerstraße durch die Reichenau zur Grenobler Brücke.
      Machbarkeitsuntersuchung | proposed inauguration: noch offen
      outlined on the trackmap

    • Bürgerstraße

      Einbau einer Verbindungskurve von der Straße Innrain in die Bürgerstraße
      in Bau | proposed inauguration: noch offen
      drawn on the trackmap

    profile

    inauguration:
    		15.07.1905
    track gauge:
    		1000 mm
    overhead wiring:
    		900 VDC
    network, total length:
    		44,8 km
    thereof Stubaitalbahn:
    		18,2 km
    stops:
    		80
    rolling stock (2018)
    trams:
    		32
    maintenance vehicles:
    		7
    historic vehicles:
    		32

    last updates

    • 04.11.2023
      NMew track connection at Claudiastraße.
    • 06.03.2023
      New line to Rum inaugurated.
    • 23.02.2020
      Line to Rum under construction.
    • 26.01.2019
      Inauguration of the new route to Josef-Kerschbaumer-Straße and new lines 2 & 5.
    • 17.12.2018
      Several current changes.
    • 12.03.2018
      New line at Amraser Straße, Planning in Völs updated.

    Found a mistake?

    You've found a mistake in the map or you know a current change? Here you can directly advise it. This will be considered in the next update.

    Updates of the maps will be done about every month. You will get a message when the update is done.
